VMAXMOTO Mini Tiller VMT500 CW 170F Engine
Description
VMAXMOTO VMT500 Specifications
| Model | 5.5HP | 6.5HP |
|---|---|---|
| Engine Type | 4 Stroke, OHV, horizontal single cylinder | |
| Displacement (mL) | 163 | 196 |
| Bore x Store (mm) | 68 x 45 | 68 x 45 |
| Rated Power [kW / (r/min)] | 3.2 / 3600 | 3.8 / 3600 |
| Max. torque [N.M / (r/min)] | 8.8 / 2600 | 10.7 / 2500 |
| Cooling System | Forced air-cooled | |
| Ignition System | Non-contact transistor shaft | |
| Power output mode | Horizontal power shaft | |
| Engine Oil grade | 10W / 40 | |
| Fuel consumption (g/kW.h) | 395 | |
| Fuel grade | Unleaded gasoline 90# | |
| Measured sound pressure / power level, [dB(A)] | 77.8 / 97.8 | |
| Vibration, (m/s2) | 14.482 | |
| Product ratio (m2/h) | 534-1068 | |
| Tilling Width (mm) | 800-1200 | |
| Tilling Depth (mm) | 120-180 | |
| Tilling Diameter (mm) | 270 | |
| Cover factor (%) | >50 | |
| Weight (kg) | 73 | |
| Dimensions (L x W x H) (mm) | 1380mm(L) x 650mm(W) x 970mm(H) | |
