BOSCH GBH 5-40 DCE Rotary Hammer
BOSCH GBH 5-40 DCE is one of Bosch’s SDS max rotary hammer for comfortable handling in extensive applications
- Vibration Control and lightweight design for effortless and continuous work in time-intensive applications
- Durable due to robust metal components and optimised lubrication system
- Powerful motor enables the delivery of 8.8 J of impact energy for fast drilling and high removal rate
Product Highlights
The GBH 5-40 DCE Professional is uniquely designed within Bosch’s SDS max corded rotary hammer category for comfortable handling and reduced user fatigue in extensive applications. Its Vibration Control and lightweight design enable effortless and continuous work in time-intensive tasks. The rotary hammer is also built for durability, featuring robust metal components and an optimised lubrication system. Its strong motor enables the delivery of 8.8 J of impact energy for a fast drilling progress and high material removal rate.
Equipment & Application
This tool is intended for drilling up to 40 mm in diameter and light chiselling work in concrete and stone. It is compatible with various dust attachments.
Additional Information
The GBH 5-40 DCE Professional also features Constant Speed, Rotation Control Clutch, and Speed Selection.
Technical Specifications
|
Impact rate at rated speed |
1,500 – 2,980 bpm |
|
Rated speed |
165 – 330 rpm |
|
Tool holder |
SDS max |
|
Impact energy (according to EPTA 05/2016) |
8.8 J |
|
Rated input power |
1,150 W |
|
Packaging dimensions (width x length x height) |
410 x 615 x 145 mm |
|
Voltage, electrical |
240 V |
|
Weight |
6.8 kg |
|
Drilling dia. concrete, hammer drill bits |
12 – 40 mm |
|
Opt. appl. range concrete, hammer drill bits |
18 – 32 mm |
|
Drilling dia. concrete, breakthrough drill bits |
45 – 55 mm |
|
Drilling diameter in concrete with core cutters |
40 – 90 mm |
|
Vibration emission value ah (Hammer drilling in concrete) |
13.5 m/s² |
|
Uncertainty K (Hammer drilling in concrete) |
1.5 m/s² |
|
Vibration emission value ah (Chiselling in concrete) |
10.5 m/s² |
|
Uncertainty K (Chiselling in concrete) |
1.5 m/s² |
