PUMA DRH150 Refrigerated Air Dryer
Description
PUMA DRH150 Refrigerated Air Dryer Key Features
- Suitable for high-temperature air inlet application.
- The maximum inlet temperature of 80°C.
- Extra pre-cooler and strong cooling fan to cool down the air and produces perfect dry air with a dew point of 2°C at 7kg/cm².
- Product of Taiwan.
Technical Specifications
|
Air |
NM³/min : 21
SCFM : 742 |
|
Horsepower (HP) |
100 HP |
|
Inlet Temperature |
≦80°C |
|
Ambient Temperature |
≦38°C |
|
Dew Point |
2-10°C (7Kg/cm²) |
|
Working Pressure |
7Kg/cm² Max. 10Kg /cm² |
|
Refrigerant |
R-22 |
|
Refrigerate Compressor (KW) |
3.1 kW |
|
Power |
220 / 380 / 440V 3 phase |
|
Connector Pipe Size |
3″ F |
|
Dimensions (mm) |
1300 x 700 x 1465 |
|
Weight(kg) |
378 |
