MOTOYAMA MPG3800 Technical Specification
Engine Specifications
|
Engine Model |
SFE200 |
|
Engine Type |
Single Cylinder, 4 Stroke, OHV, Air Cooled |
|
Horse Power (HP) |
6.5 |
|
Power Output (kW) |
4.7 / 4000rpm |
|
Bore X Stroke (mm x mm) |
68 x 54 |
|
Compression Ratio |
8.5 |
|
Starting System |
Recoil |
|
Ignition System |
T.C.I |
|
Displacement (cc) |
196 |
|
Fuel Tank Capacity (L) |
15 |
|
Oil Capacity (L) |
0.6 |
Generator Specifications
|
Rated Frequency (Hz) |
50 – 60 |
|
Rated Voltage (V) |
110/115/120/220/230/240 |
|
Voltage Regulator System |
AVR |
|
Max. Output (kW) |
60Hz : 3.1 kW
50Hz: 2.8 kW |
|
Power Factor |
1 |
|
Charging Voltage (V) |
12 (DC) |
|
Charging Current (A) |
8.3 (DC) |
|
Noise dB(A)(?7m) |
68 dB(A) |
|
Continuing Time (h) @75% Rated Output Power |
11.5 |
|
Fuel Consumption (g/kW.h) |
390 |
|
Dimension (L X W X H) (mm) |
625 x 460 x 465 |
|
Net Weight (Kg) |
47.2 / 56 |
