MOTOYAMA MPG4800E2 Gasoline Generator
Description
MOTOYAMA MPG4800E2 Technical Specification
Engine Specifications
|
Engine Model |
SFE270 |
|
Engine Type |
Single Cylinder, 4 Stroke, OHV, Air Cooled |
|
Horse Power (HP) |
9 |
|
Power Output (kW) |
6.5 / 4000rpm |
|
Bore X Stroke (mm x mm) |
77 X 58 |
|
Compression Ratio |
8.2 |
|
Starting System |
Electric |
|
Ignition System |
T.C.I |
|
Displacement (cc) |
270 |
|
Fuel Tank Capacity (L) |
25 |
|
Oil Capacity (L) |
1.1 |
Generator Specifications
|
Rated Frequency (Hz) |
50 – 60 |
|
Rated Voltage (V) |
110/115/120/220/230/240 |
|
Voltage Regulator System |
AVR |
|
Max. Output (kW) |
60Hz : 3.4 kW
50Hz: 3.1 kW |
|
Power Factor |
1 |
|
Charging Voltage (V) |
12 (DC) |
|
Charging Current (A) |
8.3 (DC) |
|
Noise dB(A)(?7m) |
69 dB(A) |
|
Continuing Time (h) @75% Rated Output Power |
17.5 |
|
Fuel Consumption (g/kW.h) |
360 |
|
Dimension (L X W X H) (mm) |
805 X 540 X 580 |
|
Net Weight (Kg) |
65.6 / 80.7 |
