YANMAR Tiller YZC-D
Rotary Tiller YZC series
- More efficient with 3 speed levels forward, 1 speed level reverse
- Transmission gear chain combinations, dual part system
- The main clutch (street) compound dry disc, dog clutch steering clutch
- Number of rotary blades 18 pcs
- Horizontal Diesel – 4 stroke water cooled with direct injection
The use of hand tractors series YZC
With 3 levels of speed and length selection handle 2 column. As well as with the many choices implement, YZC series very suitable for use in all fields.
Various type of Cage Wheel
Suitable for working in the dry and wet field
Yanmar Engine TF Series
Yanmar Engine TF Series are powerful, fuel effcient, and low vibration
Engine Specifications
|
Models |
TF 105 ML-di |
|
Type |
Horizontal Diesel Engine 4 Stroke Water Cooled |
|
Output Maximum [hp/rpm] |
10.5/2400 |
|
Output Continuous [hp/rpm] |
9.5/2400 |
|
Displacement [cc] |
583 |
|
Combustion System |
Direct Injection |
|
Cooling System |
Radiator |
|
Starting system |
Manual |
|
Fuel |
Diesel |
|
Fuel Tank Capacity [ltr] |
11 |
|
Lubricating Oil Tank Capacity [ltr] |
2.8 |
|
Weight [kg] |
102.1 |
|
Vibration Absorbers Systems |
Dual Balancer Shaft (Dual Balancer Shaft) |
Direct Injection Combustion System
Direct Injection combustion system with the toroidal shaped piston crown delivers spontaneous and bigger power with the fuel efficient system
Noise and vibration reduction
The noise and vibration reduction are achieved with the application of dual balancer system and the helical gear
Specifications
| Models | YZC | YZC – L | |
|---|---|---|---|
| Dimension with Rubber Tire (Cage Wheel) | Length [mm] | 2150 | 2425 |
| Width [mm] | 855 (1390) | 855 (1418) | |
| Height [mm] | 1230 (1330) | 1173 (1238) | |
| Weight (Frame) [kg] | 177.7 (200.5) | 188.9 (208.9) | |
| Weight (Rotary) [kg] | 68.6 | 69 | |
| Transmission | System | Gear Chain Combination | Gear Chain Combination |
| Gear Case Type | Dual Part System | Dual Part System | |
| Speed Level | Forward 3: Reverse 1 | Forward 3: Reverse 1 | |
| Clucth System | Main | Dry Multiple Disc Clutch | Dry Multiple Disc Clutch |
| Steering | Dog Clutch | Dog Clutch | |
| Brake System | System | Center Drive | Center Drive |
| Plowing Width [mm] | 660 | 660 | |
| Total Rotary Blade [pcs] | 18 | 18 | |
