YANMAR YTG5.0S Generator
Get more power and portable with Yanmar YTG5.0S Series
A robust and durable diesel generator available in capacity range from 5kW to 12kW models (Single Phase /3 Phase). Delivering high power with lower fuel consumption for your equipment. It has Auto Voltage Regulator (AVR), brushless alternator and easy for maintenance. Reliable water-cooled diesel generators powered by Yanmar TF/TS series.
Alternator Specifications
|
Alternator Model |
S16F-180/B |
|
Alternator Weight |
33.2 Kg |
|
Insulation Class |
H |
|
Operation Condition |
Ambient temperature not exceeding 5°C |
Engine Specifications
|
YANMAR |
TF90M |
|
Type |
Horizont al, 4-cycle, water- cooled diesel engine |
|
Bore x stroke |
85 x 87 mm |
|
Displacement |
0.493 L |
|
Cont. output |
8.5 HP |
|
Rated output |
9.5 HP |
|
Revolutions |
2400 min-1Â (rpm) |
|
Starting system |
Hand Starting or electric starting (optional) |
|
Cooling system |
Radiator |
|
Lubricating system |
Fully sealed forced lubrication with trochold pump & hydrauliecg rulator valve |
|
Combustion system |
Direct injection |
|
Lub. Oil capacity liters |
2.2 L/h |
|
Fuel tank capacity |
10.5 L |
Generator Specifications
|
Capacity |
5 kVA |
|
Frequency |
50Hz / 60Hz |
|
Revolutions |
3000 for 50Hz /3600 for 60Hz |
|
No. of phase |
Single Phase (2 Wire) |
|
Power factor |
1 |
|
Excitation system |
Brushless, self-excitation system |
|
Drive system |
V-belt drive |
|
Voltage (Standard) |
220 V |
|
Recommend cable dia |
6-16 mm |
|
Recommend earth cable |
Equal to the conductor size |
|
Ampere |
22.7 A |
DimensionÂ
|
Dimension Length |
1170 mm |
|
Dimension Width |
480 mm |
|
Dimension Height |
600 mm |
|
Net Weight (dry) |
170 Kg |
