DENKO KDE6500EW Diesel Generator
Description
DENKO KDE6500EW Features
– Automatic Voltage Regulator : Provides low fluctuation power output for operation of sensitive electronic equipment.
– Oil Alert Function : Stops the engine when oil drops to a specified low level
– Large Fuel tank : Allow long continuous operation hours
– Fuel Gauge : Easy monitor of fuel level
– DC Output : Enable charging of batteries
– Rugged Full Frame : Protect welder from rough handling and damage.
– Wheel Kit: Provide for easy movement.
Technical Specifications
|
Frequency (Hz) |
50 – 60 |
|
Continuous Output (kW) |
2.0 – 2.2 |
|
Maximum Output (kW) |
2.2 – 2.4 |
|
Phase |
Single |
|
Rated Voltage (V) |
230 , 240 / 120 (60Hz) |
|
DC Output (A) |
7.4 – 8.3/16.7 |
|
Engine Model |
186FA |
|
Engine Type |
Vertical, 4 Cycle, Air Cooled Diesel Engine |
|
Engine Speed (r/min) |
3000 – 3600 |
|
Rated Power Factor |
1.0 |
|
Excitation System |
Transistorized Self-excitation constant voltage (AVR) |
|
Noise Level at 7m dB (A) |
74 – 79 |
|
Fuel Tank Capacity (L) |
15 |
|
Net Weight |
110 |
|
Dimensions (cm) |
72 x 48 x 65 |
|
Welder Rated Output |
DC160A |
|
Welding rod (mm) |
2.0 – 4.0 |
