Description
IWELD GMAW200DI Features:
- Use powerful IGBT switches and advanced inverter control technology.
- Use digital and PWM control technology. The products belong to a high technology inverter welding machine.
- DC MIG/MAG, MMA welding process methods can be selected.
- Welding wire diameters (0.8, 1.0mm) can be selected.
- Excellent arc characteristics, good welding performance and little spatter.
- High weld quality, deep bath and strength. Lower heat input, small deformation after welding. Minimizing, lightness, it can be moved easily, and energy savings up to 30%.
- With auto protection functions of over current and over-heat.
- The welding material of the thin, medium and heavy plate can be welded.
- Be able to weld all kinds of metal, for example, carbon steel, stainless steel, aluminium alloy, etc.
Applications
1. Construction & Assembly Sites
2. Light Industry Iron & Steels Processing Factories
3. Home & Furniture Application
4. Equipment Assemble & Repairs
5. General Application
Main Specification
| Input Voltage (V) | One phase 240V + 15% |
| Frequency (HZ) | 50/60 |
| Rated input current(A) | 26.5 |
| Output current(A) | 30-200 |
| Rated output voltage(V) | 16.5-26.5 |
| Rated Duty Cycle (%) | 60 |
| Power factor | 0.73 |
| Efficiency(%) | ≥80 |
| Wire feed speed(m/ min) | 3-15 |
| Post flow time(S) | 1.0±0.5 |
| Wire diameter(mm) | 0.8/1.0 |
| Insulation grade | F |
| Housing protection grade | IP21S |
| Applicable thickness(mm) | over 1.0 |
| Weight (kg) | 23.9 |
| Dimensions (mm) | 620 x 360 x 450 |
