BOSCH GDX 18V-210 C prevents damage before it occurs – impact driver with 2-in-1 tool holder
- User interface with two default modes, selftapping and wood screw. Further modes can be adjusted and individualised via the Toolbox App
- 2-in-1 tool holder with 1/4” internal hex and 1/2” square drive for highest flexibility and broadest application
- Convenient three speed/torque settings for superior power control
Product Highlights
Built for strength, the powerful GDX 18V-210 C Professional impact driver delivers a high level of flexibility and damage prevention. Two default modes available on the user interface, selftapping screw (A) and wood screw (B), prevent broken or stripped off screwheads, worn-out threads, and damaged workpieces by slowing down or shutting off the impact driver. All modes are customisable via the Bosch Toolbox App. The 2-in-1 tool holder facilitates quick and flexible changeover between 1/4” internal hex and 1/2” square drive tools. Power is adjustable via three speed/torque settings, offering advanced flexibility and control.
Equipment & Application
This impact driver can be used in many applications, such as driving in selftapping or wood screws, or for tightening and removing metal bolts and nuts (M 6 – M 16). It is compatible with all Bosch Professional 18 V batteries and chargers (Professional 18V System). Also compatible with AMPShare, the multi-brand battery alliance.
Additional Information
The GDX 18V-210 C Professional is equipped with a status indicator, belt clip, and LED light for improved visibility.
Technical Specifications
|
Torque adjustment range, min./max., 1st level |
0/130 Nm |
|
Torque adjustment range, min./max., 2nd level |
0/160 Nm |
|
Torque adjustment range, min./max., 3rd level |
0/210 Nm |
|
No-load speed |
0 – 3,400 rpm |
|
No-load speed (1st level) |
0 – 1,100 rpm |
|
No-load speed (2nd level) |
0 – 2,300 rpm |
|
No-load speed (3rd level) |
0 – 3,400 rpm |
|
Torque settings |
3 |
|
Weight excl. battery |
1.2 kg |
|
Torque, max. |
210 Nm |
|
Impact rate |
0 – 4,100 bpm |
|
Impact rate (1st level) |
0 – 2,200 bpm |
|
Impact rate (2nd level) |
0 – 3,100 bpm |
|
Impact rate (3rd level) |
0 – 4,100 bpm |
|
Battery voltage |
18.0 V |
|
Tool holder |
1/4” Hex Uni, 1/2” Square |
|
Breakaway torque, max. |
370 Nm |
|
Packaging dimensions (width x length x height) |
1 x 1 x 1 mm |
|
Vibration emission value ah (Tightening screws and nuts of maximum permitted size) |
9.8 m/s² |
|
Uncertainty K (Tightening screws and nuts of maximum permitted size) |
1.5 m/s² |
