BOSCH GSB 162-2 RE Impact Drill
BOSCH GSB 162 – 2 RE has a high-power 2-gear impact drill for the toughest work and diamond dry-drilling
- Extremely powerful 1,500 W motor with high overload capacity and high torque is ideal for heavy-duty applications
- Optimised speed for fast drilling progress up to 162 mm in diameter even with diamond core cutters without impact function
- Rotation control clutch for an increased level of user protection even when working in the toughest materials
Product Highlights
The GSB 162-2 RE Professional is a high-powered 2-gear corded impact drill designed for the toughest applications including diamond dry-drilling. Its extremely strong 1,500 W motor with a high overload capacity and high torque is ideal for intense and heavy-duty applications. Its speed is specifically optimised to enable a fast drilling progress up to 162 mm in diameter even when using diamond core cutters in the non-impact function. The impact drill’s rotation control clutch ensures an increased level of user protection even when working in the toughest materials.
Equipment & Application
This tool is intended for drilling in masonry, stone, wood, and metal.
Additional Information
The GSB 162-2 RE Professional also includes features such as restart protection and speed selection.
Technical Specifications
|
Rated input power |
1,50 |
|
No-load speed, 1st gear |
0 – 750 rpm |
|
No-load speed, 2nd gear |
1,800 rpm |
|
Power output |
840 W |
|
Weight |
4.8 kg |
|
Rated speed |
555 / 1,300 rpm |
|
Rated torque |
17.0 / 5.0 Nm |
|
Drill spindle connecting thread |
5/8″-16 UNF |
|
Chuck capacity, min./max. |
3 – 16 mm |
|
Impact rate at no-load speed |
0 – 12,750 / 30,600 bpm |
|
Packaging dimensions (width x length x height) |
335 x 550 x 150 mm |
|
Voltage, electrical |
240 V |
|
Bit holder |
5/8″-16 UNF |
|
Drilling diameter in Wood |
50 / 32 mm |
|
Drilling diameter in Steel |
20 / 14 mm |
|
Drilling diameter in Masonry |
162 / 82 mm |
|
Vibration emission value ah (Drilling in metal) |
6 m/s² |
|
Uncertainty K (Drilling in metal) |
1.5 m/s² |
|
Vibration emission value ah (Impact drilling in concrete) |
23 m/s² |
|
Uncertainty K (Impact drilling in concrete) |
3 m/s² |
|
Vibration emission value ah (Screwdriving) |
1.5 m/s² |
|
Uncertainty K (Screwdriving) |
0 m/s² |
|
Vibration emission value ah (Thread-cutting) |
1.5 m/s² |
|
Uncertainty K (Thread-cutting) |
0 m/s² |
