About MAKITA TW004G Cordless Impact Wrench
- Increased motor speed under load delivers higher torque than DTW300 and DTW301
- Electronic 4 stage impact power selection for added versatility
- 3 modes of reaction time for automatic stop available both in forward and reverse rotation modes
- Trigger switch with full speed mode allows for less hand and finger fatigue
- Compact design with a short overall length of 144 mm
Technical Specifications
| Capacity | Standard Bolt: M10 – M20 (3/8 – 3/4″)
High Strength Bolt: M10 – M16 (3/8 – 5/8″) |
| No load speed (rpm) | Max / Hard / Med / Soft: 0 – 3,200 / 2,600 / 1,800 / 1,000 |
| Impacts per minute (ipm) | Max / Hard / Med / Soft: 0 – 4,000 / 3,400 / 2,600 / 1,800 |
| Max. fastening torque | 350 N·m (260 ft.lbs.) |
| Nut-Busting Torque | 630 N·m (465 ft.lbs.) |
| Square Drive | 12.7 mm (1/2″) |
| Dimensions (L x W x H) | w/ BL4025: 144 x 86 x 248 mm
w/ BL4040: 144 x 86 x 253 mm |
| Net weight | 1.9 – 2.2 kg (4.2 – 4.9 lbs.) |
