BOSCH GBH 18V-22 has a evolve, with our most compact and ergonomic Boschhammer
- More comfort and less strain while drilling, even during overhead work
- Lightweight hammer drilling with specially designed clip-on dust extractor
- Uninterrupted work thanks to improved runtime
Product Highlights
Muscle strain, unexpected jolts, and dust inhalation are just some of the hazards you face when drilling in concrete. Fortunately, we’ve developed the GBH 18V-22 Professional rotary hammer to make your job more comfortable. This tool is compact, light, and ergonomically designed with a well-defined centre of gravity, so you will find it easier and less tiring to handle it, especially when drilling overhead. You stay in control and there’s less impact on your hands and arms thanks to KickBack Control and Vibration Control. Connect the hammer to the GDE 18V-12 Professional dust extractor with just one click for a cleaner site while you work. And you can wrap up the job with less interruptions too – this tool combines high performance with efficient battery runtime.
Equipment & Application
The GBH 18V-22 Professional rotary hammer is your tool of choice if you want a powerful but manageable power tool. It is ideal for drilling 6 mm to 10 mm holes, whether you are a plumber putting in sanitary installations or a carpenter prepping a site for a kitchen installation. Equally, if you are an electrician, you can count on this tool, particularly when drilling overhead to install lighting, lamps, and smoke detectors. The GDE 18V-12 Professional dust extractor is specially designed to facilitate overhead work. Compatible with the Bosch Professional 18V System and with the multi-brand battery alliance AMPShare.
Technical Specifications
|
Impact energy (according to EPTA 05/2016) |
1.9 J |
|
Impact rate at rated speed |
0 – 4,675 bpm |
|
Rated speed |
0 – 1,050 rpm |
|
Battery voltage |
18.0 V |
|
Weight excl. battery |
2.3 kg |
|
Tool holder |
SDS plus |
|
Packaging dimensions (width x length x height) |
220 x 340 x 100 mm |
|
Drilling dia. in concrete with hammer drill bits |
4 – 22 mm |
|
Opt. app. range in concrete with hammer drill bits |
4 – 12 mm |
|
Vibration emission value ah (Hammer drilling in concrete) |
14 m/s² |
|
Uncertainty K (Hammer drilling in concrete) |
1.5 m/s² |
|
Vibration emission value ah (Chiselling in concrete) |
9.4 m/s² |
|
Uncertainty K (Chiselling in concrete) |
1.5 m/s² |
