DAB K28/500T Industrial Pump

DAB Industrial K28/500T Description

DAB K-Single-impeller centrifugal pump suitable for domestic, civil, industrial and agricultural systems, and for decanting, mixing and irrigation uses.

CONSTRUCTION FEATURES OF THE PUMP

• Pump body and motor support in cast iron. Technopolymer or cast iron impeller, as per the TECHNICAL DATA table. Carbon/ceramic mechanical seal.

CONSTRUCTION FEATURES OF THE MOTOR

• Closed asynchronous type, external ventilation cooling. Rotor running on ball bearings, oversized to ensure low noise and durability. Standard built-in thermo-amperometric protection. Capacitor permanently fitted on single phase versions. For the protection of the three-phase motor, we recommend the use of remote overload cut-outs, in compliance with current local regulations. Construction according to CEI 2-3. IE2 motors as standard, from 0,75 kW to 5,5 kW – IE3 ≥ 7,5 kW

Technical Specifications
