Description

YANMAR YDP40N Description

YANMAR YDP Series provides industry-leading pumping capabilities for applications around the world. And as it is now EU Stage-V compliant and CE marked, the series meets the highest emissions standards globally. High quality components and a renowned Yanmar direct injection ensure optimal, low-cost performance backed by easy maintenance and a two-year warranty. And as the pumps are manufactured at a Yanmar facility in Europe your Yanmar support partner is there for swift back-up standards.

Features

A proven performer, now EU Stage-V compliant

  • Having proved its credentials in some of the world’s harshest working environments the enhanced and durable YDP Series of diesel pumps is now EU Stage-V and CE certified, bringing their performance excellence into Europe.

Industry-leading features including electric starting

  • The durable and dependable new 44-model YDP Series offers a range of features aimed at increasing productivity and run-time including an advanced Yanmar engine, much larger than standard fuel tanks and electric starting.

Operator friendly

  • The low noise, low vibration YDP pumps are easier than ever to maintain and are compact and simple to transport due to their optional wheel kit – and all supported by an attractive two-year warranty.

Low fuel consumption and versatile power outputs

  • The cutting-edge, direct injection, four-stroke Yanmar engine ensures low fuel consumption. Available in a range of power outputs to suit numerous applications and varying content from fresh water to liquid with significant amounts of debris.

High performance and high output

  • Each model boasts a high output ranging from 500 up to 1.750 liters per minute coupled with low noise and vibrations.



Technical Specification

Starting System Recoil
Engine Fuel Diesel
Max. Capacity 1300 L/min
Suction & Discharge Diameter 100 mm
Region of Use Non- Regulated
Engine Model L70N6-PY12
Engine Type 4 Stroke, Air Cooled Diesel Engine
Displacement 320 cc
Max Output 4.9 kW / 3600 rpm
Continuous Output 4.4 kW / 3600 rpm
Fuel Oil Tank Capacity 13 L
Dimension (mm) 630 x 484 x 727
Dry Weight Recoil 62 Kg
Dry Weight Electric 77 Kg
Suction Lift 7 m
Maximum Total Head 26.5 m
