PENTAIR Sand Filter MDL1252
Description
Pentair Structural Polyglass Vessels 1252
Pentair® Structural® Polyglass Vessels have been the industry standard for quality and performance for more than 40 years. Featuring a one-piece, seamless, high-density polyethylene liner and an encapsulated, leak-free engineered polymer inlet, Structural Polyglass Vessels are designed to provide you with years of worry-free performance.
Features
- For residential and light commercial water softener/filtration applications
- Slim diameter with capacities from 2 to 49 gallons
- 1.25″ Dome Port opening available on select sizes for neutralizing applications
- Unmatched strength and chemical resistance
- 10-year warranty for 6″ – 13″ vessels
- 5-year warranty for 14″ – 16″ vessels
Material of Construction
- Inner shell of high-density polyethylene
- Threaded inlet available in various sizes: 2.5″, 4″, 4.5″
Pentair Design Parameters
- Safety factor – 4:1
- Minimum burst at 600 psi
- Tested to 250,000 cycles without leakage
Applications
- Residential/light commercial softening
- Residential/light commercial filtration
- Portable exchange tanks
NSF/ANSI STD.44 Design Parameters
- Safety factor – 4:1
- Minimum burst at 600 psi
- Tested to 100,000 cycles without leakage
Operating Parameter
- Maximum operating pressure – 150 psi
- Maximum operating temperature – 120° F
Technical Specifications
|
Max Pressure psi |
150 |
|
Max Pressure bar |
10.3 |
|
Max Temperature °C |
120.0 |
|
Max Temperature °F |
49 |
|
Material |
Polyethylene |
|
Capacity Gallon |
22.2 |
|
Capacity Liter |
84.0 |
|
Diameter inch |
Ø12 |
|
Diameter mm |
Ø305 |
